FS105D 5.0 5-Port 10/100Mbps Ethernet Switch
1Gbps Switching Capacity, 2,048 MAC Address Table & 0.744 Mpps
USB-C 5V Power, Basic Power Saving & Desktop/Wall-Mount Installation
| Network Switch | |
| Model | FS105D 5.0 |
|---|---|
| Product Type | 5-Port 10/100 Mbps Ethernet Switch |
| RJ45 Ports | 5 × 10/100 Mbps |
| Power Interface | USB-C |
| Power Input | 5V ⎓ 1A |
| Maximum Power Consumption | 0.5W |
| Idle Power Consumption | 0.32W |
| Power Saving | Basic Power Saving |
| LED Indicators | |
| Power LED | Yes |
| Link/ACT LED | Each Ethernet Port |
| Performance | |
| MAC Address Table | 2,048 |
| Switching Capacity | 1 Gbps |
| Forwarding Rate | 0.744 Mpps |
| Packet Buffer | 570 Kbit |
| Ethernet Speed & Distance | |
| Cat. 3 or Higher Cable | Up to 100m at 10 Mbps |
| Cat. 5 or Higher Cable | Up to 100m at 100 Mbps |
| Network Standards | |
| 802.3i | 10BASE-T |
| 802.3u | 100BASE-TX |
| Operating Environment | |
| Operating Temperature | 0°C to 40°C (32°F to 104°F) |
| Storage Temperature | -40°C to 75°C (-40°F to 167°F) |
| Operating Humidity | 10% to 90%, non-condensing |
| Storage Humidity | 5% to 90%, non-condensing |
| Mechanical | |
| Dimensions | 88 × 52.5 × 24 mm |
| Dimensions (Inches) | 3.46 × 2.07 × 0.94 inches |
| Casing Material | Plastic |
| Installation | Desktop / Wall-Mount |
| Package Contents | |
| FS105D 5.0 | 1 × |
| Power Cable | USB-A to USB-C |
| Documentation | Installation Guide |
| Warranty | |
| Brand Warranty | 1 Year |
The TP-Link FS105D 5.0 is a compact 5-port 10/100 Mbps Ethernet switch designed for simple and reliable wired network expansion. It features five 10/100 Mbps RJ45 ports, allowing multiple compatible devices to be connected to the same network.
The switch supports 10BASE-T and 100BASE-TX networking standards and provides up to 1 Gbps switching capacity with a forwarding rate of up to 0.744 Mpps. Its 2,048-entry MAC address table and 570 Kbit packet buffer support efficient handling of network traffic.
The FS105D 5.0 uses USB-C power input with a 5V/1A power requirement and has a maximum power consumption of just 0.5W. It also features basic power-saving functionality, making it suitable for everyday networking environments.
With a compact plastic casing and both desktop and wall-mount installation options, the switch is suitable for homes, offices, small businesses, CCTV networking, and other basic wired network setups.
