2MP F1.0 Full-Color Eyeball IP Camera with 30m Warm Light
1920×1080 Resolution, 2.8mm/3.6mm Fixed-Focal Lens & 20m IR
SMD Plus, Human & Vehicle Detection, Built-in Mic, PoE & IP67
| Camera | |
| Image Sensor | 1/2.8" CMOS |
|---|---|
| Camera Type | Eyeball IP Camera |
| Pixels | 2MP |
| Resolution | 1920 × 1080 |
| Shutter Speed | 1/3s–1/100,000s |
| Focus Range | 1.1m (2.8mm) / 1.7m (3.6mm) |
| SMD Plus | Supported |
| Human Detection | Supported |
| Vehicle Detection | Supported |
| Lens | |
| Lens Type | Fixed-Focal |
| Focal Length | 2.8mm / 3.6mm |
| Maximum Aperture | F1.0 |
| Field of View | 2.8mm / 3.6mm |
| Focus | Fixed-Focal |
| Illuminator | |
| IR Distance | Up to 20m |
| Warm Light Distance | Up to 30m |
| Illumination | IR + Warm Light |
| Illuminator | 1 IR LED + 1 Warm Light |
| Video | |
| Video Resolution | 1080p / 1.3MP / 720p / D1 / VGA / CIF |
| Video Compression | H.265 / H.264 / H.264H / H.264B / MJPEG |
| Smart Codec | Supported |
| Stream Capability | 2 Streams |
| Main Stream | Up to 1920 × 1080 @ 25/30fps |
| Day & Night | Auto (ICR) / Color / B/W |
| Shutter Speed | 1/3s–1/100,000s |
| Image Enhancement | |
| WDR | DWDR |
| BLC | Yes |
| HLC | Yes |
| Noise Reduction | 3D NR |
| ROI | Supported |
| SMD Plus | Supported |
| Human & Vehicle Detection | Supported |
| Audio | |
| Built-in Microphone | Yes |
| Audio Compression | G.711a / G.711Mu / PCM / G.726 |
| Network | |
| Network Interface | RJ-45 10/100 Base-T |
| PoE | Supported |
| ONVIF | Profile S & T |
| Compatible OS | iOS / Android / Windows |
| Power | |
| Power Supply | 12V DC / PoE |
| PoE Standard | IEEE 802.3af |
| Power Consumption | Max. 4.8W (PoE) |
| Protection | |
| Water & Dust Protection | IP67 |
| Physical Information | |
| Casing Material | Metal + Plastic |
| Dimensions | 85.5mm × Φ109mm |
| Built-in Flash | No |
| Red-Eye Reduction | No |
| Warranty | |
| Warranty | 1 Year |
The Dahua DH-IPC-HDW1239T1-A-PRO is a 2MP fixed-focal eyeball IP camera designed for reliable surveillance in homes, offices, shops, warehouses and other security applications. It features a 1/2.8" CMOS sensor with 1920 × 1080 resolution and supports up to 25/30fps for clear and smooth Full HD video monitoring.
The camera uses a bright F1.0 fixed-focal lens available in 2.8mm and 3.6mm options. The 2.8mm lens provides a 104° horizontal viewing angle, while the 3.6mm lens provides an 88° horizontal viewing angle. For night surveillance, it features 1 IR LED and 1 warm light, with both IR and warm-light illumination reaching up to 30 meters.
For improved image quality and surveillance accuracy, the DH-IPC-HDW1239T1-A-PRO supports DWDR, BLC, HLC and 3D noise reduction. SMD Plus with Human and Vehicle Detection helps identify relevant targets and reduce unnecessary detection events. The camera also supports ROI, privacy masking and other image configuration features.
The camera includes a built-in microphone with G.711a, G.711Mu, PCM and G.726 audio compression support. It supports H.265, Smart H.265+, Smart H.264+ and other compression technologies with two-stream capability, helping optimize bandwidth and storage usage.
For convenient installation, the DH-IPC-HDW1239T1-A-PRO supports 12V DC and IEEE 802.3af PoE through its 10/100 Base-T RJ-45 network interface. Its IP67 protection and metal + plastic construction provide protection against dust and water for suitable surveillance installations. The camera comes with a 1-year warranty.
