The Uniview IPC3614LB-AF28K-DL2 is a 4MP Dual-Light PoE Dome IP Camera designed for reliable network surveillance. It features a 1/3.0-inch CMOS sensor with a maximum resolution of 2560 × 1440 at up to 25fps, along with a 2.8mm fixed F1.6 lens that provides a wide 93.2° horizontal field of view.
The camera delivers detailed 4MP video at 2560 × 1440 resolution up to 25fps. It also supports 3MP at up to 30fps and 1080P at up to 30fps for flexible video configuration.
The 2.8mm fixed lens with F1.6 aperture provides a 93.2° horizontal, 51.5° vertical, and 108.0° diagonal field of view, making it suitable for monitoring relatively wide areas.
The camera features a dual-light illumination system with both IR and warm-light illumination up to 30 meters (98.4 ft). The IR system operates at 850nm, while Smart IR helps manage infrared illumination for nighttime surveillance.
The camera also features an IR-cut filter with automatic switching (ICR) for day/night operation.
The camera supports DWDR (Digital Wide Dynamic Range) to improve image performance in varying lighting conditions. Additional image enhancement features include 2D/3D DNR, HLC, BLC, Smart IR, and Digital Defog.
It also supports multiple white-balance modes and flexible image flip options, including vertical, horizontal, 180°, and 90° rotation settings.
For efficient video transmission, the camera supports Ultra 265, H.265, and H.264 compression. H.264 supports Baseline, Main, and High profiles.
The camera provides dual video streams, with a video bitrate range of 128Kbps to 6144Kbps. It also supports U-code, up to 4 OSDs, up to 4 privacy mask areas, and ROI.
The camera supports Ultra Motion Detection, Motion Detection, Audio Detection, and Tampering Alarm. These features provide multiple event-detection options for surveillance monitoring.
A built-in microphone is included for audio capture. The camera supports AAC-LC, G.711U, and G.711A audio compression. Two-way audio is not supported, and the built-in speaker is not available.
For local recording, the camera supports MicroSD cards up to 512GB. It also supports ANR (Automatic Network Replenishment) and NAS using NFS, providing additional storage and recording options.
The camera supports both DC 12V ±25% and IEEE 802.3af PoE power supply. Its 1 × RJ45 10/100M Base-TX Ethernet port provides network connectivity.
For system integration, it supports API and SDK, up to 32 users with three user levels, and a range of network and security protocols. The camera is also compatible with EZStation and APP.
The camera features IP67 protection according to IEC 60529, helping protect against dust and water ingress. It also provides 4KV surge protection for improved protection in network surveillance installations.
The camera supports Pan 0°–360°, Tilt 0°–80°, and Rotate 0°–360° adjustment for flexible installation and positioning.
Its compact body measures Ø117.8 × 100.3mm and weighs approximately 0.26kg. The housing is made from Graphene + Plastic.
The camera provides the following DORI distances with its 2.8mm lens:
Detect: 63.0m
Observe: 25.2m
Recognize: 12.6m
Identify: 6.3m
4MP network dome camera
1/3.0" CMOS sensor
2560 × 1440 @ up to 25fps
2.8mm fixed F1.6 lens
93.2° horizontal field of view
Dual-Light illumination
30m IR + 30m warm-light distance
850nm IR
DWDR
2D/3D DNR
Smart IR
HLC, BLC & Digital Defog
Ultra 265 / H.265 / H.264
Dual video streams
ROI support
Up to 4 OSDs
Up to 4 privacy mask areas
Ultra Motion Detection
Motion, Audio & Tampering Detection
Built-in microphone
MicroSD up to 512GB
ANR & NAS (NFS)
PoE IEEE 802.3af
DC 12V ±25%
1 × RJ45 10/100M
API & SDK support
Up to 32 users with 3 user levels
IP67 protection
4KV surge protection
3-axis adjustment
63m DORI detection distance
Max. power consumption 4.2W
Overall, the Uniview IPC3614LB-AF28K-DL2 combines 4MP imaging, a 2.8mm wide-angle lens, 30m IR and 30m warm-light dual illumination, DWDR, 2D/3D DNR, built-in microphone, 512GB MicroSD support, PoE connectivity, IP67 protection, and 4KV surge protection in a compact dome camera design for dependable network surveillance.
