64-Channel 32MP NVR with 8 SATA, 384Mbps Bandwidth & 4K HDMI
The 64-Channel 32MP NVR is a high-capacity network video recorder designed for advanced IP surveillance systems. It supports 64-channel IP video input and recording resolutions of up to 32MP, with support for multiple recording resolutions including 24MP, 12MP, 8MP, 6MP, 5MP, 4MP, 3MP, 1080p, 720p and other standard formats.
The NVR supports up to 4-channel 32MP/24MP IP video inputs, making it suitable for surveillance systems that require high-resolution network camera recording. It also provides 384Mbps incoming bandwidth and 256Mbps outgoing bandwidth for handling high-volume IP video data.
This NVR supports up to 64-channel IP video input and a wide range of recording resolutions. It supports up to 4-channel 32MP/24MP IP video inputs, allowing compatible high-resolution IP cameras to be integrated into the surveillance system.
Supported recording resolutions include:
32MP
24MP
12MP
8MP
6MP
5MP
4MP
3MP
1080p
UXGA
720p
VGA
4CIF / DCIF / 2CIF / CIF / QCIF
The recorder features 2 × RJ-45 10/100/1000 Mbps self-adaptive Ethernet interfaces. It supports up to 384Mbps incoming bandwidth and 256Mbps outgoing bandwidth, providing high network throughput for IP video surveillance applications.
The NVR provides two HDMI outputs and one VGA output.
Both HDMI outputs support resolutions up to 4K (3840 × 2160) at 30Hz, along with 2K and Full HD output modes. The VGA output supports up to 1920 × 1080 at 60Hz.
This provides flexible connectivity for compatible surveillance monitors and display systems.
The NVR supports up to 8 SATA interfaces for HDD connection, providing a high-capacity storage platform for surveillance recording.
The exact maximum HDD capacity per SATA interface is not specified in the provided specification, so no unsupported storage capacity has been added.
The recorder supports 16-channel synchronous playback, allowing users to review footage from multiple camera channels simultaneously.
It also supports smart search for selected areas within video and smart playback, helping improve playback efficiency and make relevant footage easier to locate.
The NVR supports multiple VCA (Video Content Analytics) events, providing intelligent video analysis capabilities.
Smart search and smart playback functions further improve the efficiency of reviewing recorded surveillance footage.
The NVR supports a wide range of network protocols and management technologies, including:
TCP/IP
DHCP
IPv4 / IPv6
DNS
DDNS
NTP
RTSP
SADP
SMTP
SNMP
NFS
iSCSI
ISUP
UPnP™
HTTP / HTTPS
It also supports ONVIF Profile S/G, SDK and ISAPI for integration with compatible surveillance and management systems.
The NVR supports up to 128 remote connections and is compatible with IE11, Chrome V57, Firefox V52, Safari V12 and Edge V89 or above.
The recorder operates on an embedded Linux-based platform and is designed for professional network video surveillance applications. Its power input supports 100–240 VAC, 50–60Hz, allowing operation across a wide AC voltage range.
64-Channel IP Video Input
Up to 32MP Recording Resolution
Up to 4-Channel 32MP/24MP IP Video Inputs
384Mbps Incoming Bandwidth
256Mbps Outgoing Bandwidth
2 × RJ-45 10/100/1000 Mbps Ethernet Interfaces
2 × HDMI Outputs
HDMI up to 4K (3840 × 2160) at 30Hz
1 × VGA Output
VGA up to 1920 × 1080 at 60Hz
16-Channel Synchronous Playback
Smart Search & Smart Playback
Multiple VCA Events
Up to 8 SATA Interfaces for HDD
ONVIF Profile S/G Support
SDK & ISAPI Support
Up to 128 Remote Connections
Wide Network Protocol Support
100–240 VAC, 50–60Hz
440 × 457 × 94mm Dimensions
01 Year Warranty
| DVR / NVR / XVR Specification | Details |
|---|---|
| Device Type | NVR |
| IP Video Input | 64 Channels |
| Network Interface | 2 × RJ-45 10/100/1000 Mbps self-adaptive Ethernet |
| Remote Connection | Up to 128 |
| Network Protocols | TCP/IP, DHCP, IPv4, IPv6, DNS, DDNS, NTP, RTSP, SADP, SMTP, SNMP, NFS, iSCSI, ISUP, UPnP™, HTTP, HTTPS |
| API / Integration | ONVIF Profile S/G, SDK, ISAPI |
| Browser Compatibility | IE11, Chrome V57, Firefox V52, Safari V12, Edge V89 or above |
| Playback | 16-channel synchronous playback |
| Recording Resolution | Up to 32MP |
| Supported Resolutions | 32MP, 24MP, 12MP, 8MP, 6MP, 5MP, 4MP, 3MP, 1080p, UXGA, 720p, VGA, 4CIF, DCIF, 2CIF, CIF, QCIF |
| 32MP/24MP IP Input | Up to 4 channels |
| Incoming Bandwidth | 384 Mbps |
| Outgoing Bandwidth | 256 Mbps |
| Smart Features | Multiple VCA events, smart search, smart playback |
| Storage Interface | Up to 8 × SATA interfaces |
| HDMI 1 Output | 4K (3840 × 2160)/30Hz, 2K (2560 × 1440)/60Hz, 1920 × 1080/60Hz, 1600 × 1200/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz |
| HDMI 2 Output | 4K (3840 × 2160)/30Hz, 2K (2560 × 1440)/60Hz, 1920 × 1080/60Hz, 1600 × 1200/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz |
| VGA Output | 1920 × 1080/60Hz, 1600 × 1200/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz |
| Power Supply | 100–240 VAC, 50–60Hz |
| Dimensions | 440 × 457 × 94 mm (17.4 × 18.0 × 3.7") |
| Warranty | 01 Year |
This 64-Channel 32MP NVR is suitable for large-scale IP surveillance systems requiring high-resolution recording, multiple network connections and extensive HDD expansion options, including:
Commercial surveillance systems
Office and corporate security
Warehouse monitoring
Industrial surveillance
Retail and large premises
Multi-camera IP surveillance installations
Centralized video recording systems
Overall, this 64-Channel 32MP NVR with 8 SATA interfaces, 384Mbps incoming bandwidth, 256Mbps outgoing bandwidth, dual 4K HDMI outputs and 16-channel synchronous playback provides a powerful platform for high-capacity IP video surveillance and recording.
